Features :- Bare solid Copper conductor 100BASE-TX- RoHS compiled PVC/LSZH jacket 100BASE-T4- ANSI/TIA-568-C.2 & IEC 11801 complied 100BASE-T- Minimum bending radius: 8XD PoE/PoE+- Construction U/UTP- Conductor 24AWG- Insulation 0.95mm- No. of Pairs 4- Cable OD. 5.8 ± 0.5 mm- Jaket LSZHElectrical Properties:- Characteristic Impedance 100 ± 15Ω- Conductor Resistance (20°C) ≤ 9.38Ω/100m- Electrical Resistance Unbalance (20°C) ≤ 2.5%- Insulation Resistance ≥ 5000 MΩ’km- Pair to Ground Capacitance Unbalance ≤ 330 pF/100m- Mutual capacitance of a pair ≤ 5.6 nF/100m- Delay skew ≤ 45ns/100m
